High Definition Indoor P2.5 LED Screen LED Display LED Video Wall
Function and Technology Character Introduction:
1, Low brightness and high gray Using PWM constant current output LED high brush driver chip, improve the image display effect, color photography without water ripples.
2, Wide color gamut, richer color levels The product adopts high-quality lamp beads, Nova control system, can achieve ≤110% NTSC wide color gamut, and the color reproduction is better.
3, High refresh chip high refresh chip, refresh up to 3840Hz, constant output current, high refresh effect and no flicker when taking pictures.
4, The flatness error of the whole screen is less than 0.2mm, which can effectively eliminate the mosaic phenomenon
5, Wide viewing angle and high contrast. The visual viewing angle is up to 160°, which is barrier-free for viewing up, down, left, and right. It is non-reflective. The ink color of the mask has good consistency and high contrast.
Products Applications:
Widely used in churches, control command centers, video surveillance centers, high-definition information release, conference display systems and other commercial venues
SPECIFICATIONS Parameters:
| Product parameter |
| led module |
| Pixel pitch (mm) | P2.5 |
| Pixel density (point /㎡) | 160000 |
| Module size (mm) | 320X160 |
| Module resolution (WxH) | 128X64 |
| Package form | SMD2121 |
| scanning method | 1/32S |
| Refresh rate (Hz) | ≥1920/3840(Optional ) |
| White balance brightness (Nits) | ＞700 |
| Color temperature (K) | 3200-9300(Adjustable ) |
| Gray scale | ≥14bit |
| Frame change frequency | 60-120Hz |
| Viewing angle (horizontal/vertical) | 160°/160° |
| Protection level (front/back) | IP31 |
| Average/peak power consumption (W/㎡) | 850/350 |
| Face mask | NO |
| Cabinet |
| Cabinet size (mm) | 640X640 |
| Screen weight (Kg) | 7.5 |
| Cabinet module composition (WxH) | 2X4 |
| Cabinet resolution (WxH) | 320X320 |
| Flatness (mm) | ≤0.2 |
| Maintenance method | Full front maintenance |
| Cabinet material | Die-cast aluminum |
| Application Environment |
| Input voltage (V) | 110-240 |
| Operating temperature (℃) | -20~50 |
| Working humidity (RH) | 10%-95% |
| Service life (H) | ≥100000 |
| Model type (using video processor) | AV,S-Video,VGA,DVI,HDMI,SDI,DP |
| Control distance | Category 5 network cable :＜100m,Single mode fiber :＜10km |
weiye color series led strip display screen advantage:
1, Precision die-cast aluminum Cabinet. The Cabinet body is made of aluminum alloy, which is light in weight, easy to dissipate heat, and strong in hardness. After CNC processing, the precision is higher and the screen body is seamlessly spliced.
2, Create a high-quality display effect with ultra-high dynamic contrast, make the picture have a strong black and white contrast, and ensure the transparency and brightness of the picture.
3, Constant output current, no flicker when taking pictures with high refresh effect
4, Back wireless design Wireless connection between boxes, exposed wires on the screen, and internal cables using aviation plugs, which are stable and firm to ensure trouble-free power transmission. A quick lock link is used between the box body and the box body, which is convenient, fast and firm to install, and is neat and tidy at the same time.
5, Super protection, bearing collision capacity> 10kg
Product Tags:
|
|
640x640mm Fixed LED Display Screen P2.5 LED Video Wall 100000Hrs Images
|
